Lesson

A line that intersects two (or more) other lines is called a transversal. Angles formed on the same side of a transversal are called consecutive angles.

In the applet below, $f$`f` is a transversal of $g$`g` and $h$`h`. Moving the slider changes the orientation of $g$`g`. Move the slider in the applet below and notice how the measures of the highlighted angles change:

When $g$`g` and $h$`h` are parallel, the measure of the interior angles add to $180^\circ$180°. When they aren't parallel, $g$`g` intersects $h$`h` forming a third angle, and adding the measures of the two interior angles and this third angle always makes $180^\circ$180°.

Let's use the applet below to explore the different pairs of consecutive angles formed by parallel lines. Notice that angles between the parallel lines are called interior angles, and angles outside the parallel lines are exterior angles.

Formally, we can say that if two lines are parallel, then consecutive interior angles are supplementary. We refer to this as the consecutive interior angles postulate. Using properties of linear pairs allows us to prove that consecutive exterior angles are also supplementary, and this is referred to as the consecutive exterior angles theorem.

Postulate or theorem?

The consecutive interior angles postulate is **assumed** to be true, so we call it a **postulate**. Other results, such as the consecutive exterior angle theorem, are **derived** from the postulates and other results, so we call it a **theorem**.

If we look at a pair of angles on opposite sides of the transversal, we can refer to them as alternate angles. Alternate angles between the parallel lines are alternate interior angles, while alternate angles outside the parallel lines are alternate exterior angles.

Use the applet to explore the different pairs of alternate angles. What do you notice about their values?

We can use properties of linear pairs and vertical angles to prove that if two lines are parallel, then pairs of alternate interior angles are congruent - this is called the alternate interior angles theorem. It's also true that pairs of alternate exterior angles are congruent - this is called the alternate exterior angles theorem.

Corresponding angles are the angles that occupy the same relative position at each intersection. We can slide the slider in the applet below to see all four pairs of corresponding angles. What relationship do these angles have?

Using similar results to those we discussed above, we can prove that if two lines are parallel, then the corresponding angles are congruent - this is called the corresponding angles theorem.

Angles formed by a transversal to two parallel lines

If two lines are parallel, then:

- Consecutive interior angles are supplementary (the consecutive interior angles postulate)
- Consecutive exterior angles are supplementary (the consecutive exterior angles theorem)
- Alternate interior angles are congruent (the alternate interior angles theorem)
- Alternate exterior angles are congruent (the alternate exterior angles theorem)
- Corresponding angles are congruent (the corresponding angles theorem)

Consider the diagram below.

Which relationship describes the marked angles?

Alternate exterior angles

AAlternate interior angles

BConsecutive interior angles

CConsecutive exterior angles

DCorresponding angles

EAlternate exterior angles

AAlternate interior angles

BConsecutive interior angles

CConsecutive exterior angles

DCorresponding angles

E

Consider the diagram below.

Solve for $x$

`x`.

Consider the diagram below.

Solve for $p$

`p`.Solve for $q$

`q`.

Know precise definitions of angle, circle, perpendicular lines, parallel lines, and line segment, based on the undefined notions of point, line, distance along a line, and distance around a circular arc as these exist within a plane.
